110301. U/UTP Cat6A

U/UTP Cat6A, 4 pairs, PVC/PE/LSOH Jacket; 4×2×0.575 BC + OD 1.35 Foam PE + Cross + Rip Cord + OD 7.4 LSOH; 500Mhz, complied with EN50173,TIA/EIA568C.2, ISO11801

Detailed description

Description:

Shielded Copper cable, 4 pairs, Category 6A, solid
4 pairs
Cable is used for indoor installation and unshielded systems

Materials:

Conductive material: wire made of soft annealed electrolytic copper
Conductor insulation: PE, film-porous-film structure
The cable jacket: FR-PVC

Technical characteristics:

Conductor diameter: 0.57 ± 0.01mm (0.022" ± 0.004") (23 AWG)
Insulated conductor diameter: 1.43 mm (0.056")
Outer cable diameter: 8 mm (0.31")
Jacket thickness: 0.5 mm (0.019")
Pulling strength: 130 N maximum
Minimum bend radius: 50 mm (1.97")
Repeated bending: 80 cycles
Rip cord has a breaking strength of 10 kg (98 N)
Operating temperature: -30°C – +70°C (+22°F – +158°F)
Weight per 1000 ft (304.8 m): 16.8 kg (37 lbs)
Standard package: 500 m (1640 ft)

Electrical characteristics

Frequency, MHz

Attenuation, dB

NEXT, dB

PSNEXT, dB

ELFEXT, dB

PSELFEXT, dB

20.0

2.0

74.3

72.3

67.8

64.8

23.0

3.8

65.3

63.3

55.8

52.8

24.5

5.3

60.8

48.8

49.7

46.7

25.0

5.9

59.3

57.3

47.8

44.8

25.0

7.5

56.2

54.2

43.7

40.7

25.0

8.4

54.8

52.8

41.8

38.8

24.3

9.4

53.3

41.3

39.8

36.8

31.25

23.6

105

51.9

49.9

37.9

34.9

62.5

21.5

15.0

47.4

45.4

31.9

28.9

100

20.1

19.1

44.3

42.3

27.8

24.8

200

18.0

27.6

39.8

37.8

21.8

18.8

250

17.3

31.1

38.3

36.3

19.8

16.8

300

16.8

34.3

37.1

35.1

18.3

15.3

500

15.2

45.3

33.8

31.8

13.8

10.8
