152802. HD-101V HDMI Converter
  • 152802. HD-101V HDMI Converter
  • 152802. HD-101V HDMI Converter

152802. HD-101V HDMI Converter

Allow you to connect HDMI sources to a display with YPbPr interface; Convert HDMI digital signal to YPbPr and stereo audio with free; YPbPr Output resolution with the change of the input signal HDMI; Support full HDMI audio and video; No signal loss; Suitable for HDCP compliant equipments.
Detailed description

Features:

  • Allow you to connect HDMI sources to a display with YPbPr interface
  • Convert HDMI digital signal to YPbPr and stereo audio with free
  • YPbPr Output resolution with the change of the input signal HDMI
  • Support full HDMI audio and video
  • No signal loss
  • Suitable for HDCP compliant equipments
  • Plug and play, and no software installation required
  • Easy to install and simple to use

Specifications

Item

Specification

Item

Specification

Product

HDMI to YPbPr HD-101V HDCP Compliant HDCP Rev 1.2
Input Port One HDMI signal Frequency Range 25-165MHz
Output Port A set of YPbPr and stereo audio signal Vertical Frequency Range 60Hz
Input Port Connector HDMI 19pin A type Operation Temperature 0℃ to 70℃
Output Port Connector YPbPr and RCA for stereo audio Power Adapter 5V 2A
HDMI Input Standard 480i 480P 576i 576P 720P 1080i 1080P Housing Material ABS

YPbPr Output Resolution
Corresponding

480i 480P 576i 576P 720P 1080i 1080P Dimension 101*56*24.5mm
