130208. Alarm Cable Shielded, 12x(7x0,2)

130208. Alarm Cable Shielded, 12x(7x0,2)

Alarm Cable Shielded, 12x(7x0,2), 100m spool, white color

Detailed description

Alarm Cable Shielded, 12x(7x0,2), 100m spool, white colour
Conductor: CCA, TCCA or TC

Jacket: PVC or LSOH

FTECHNICAL FEATURES

CONDUCTORS Stranded bare copper conductors CEI 20-29 cl.5, EN 60228, IEC 60228 ref.	INSULATION Special halogen free low smoke compound Colour code: differently coloured
SHIELD (OPTIONAL) Aluminium/polyester tape helically wound with stranded bare copper drain wire	JACKET Special halogen free low smoke compound CEI 20-11 quality M1, VDE 0207 HM2 colour: White or on request
ELECTRICAL CONDUCTOR RESISTANCE 0,22 mm2: < 89 Ohm/Km 0,50 mm2: < 39 Ohm/Km 0,75 mm2: < 26 Ohm/Km 1,00 mm2: < 19,5 Ohm/Km 1,50 mm2: < 13,5 Ohm/Km 2,50 mm2: < 7,9 Ohm/Km	WORKING TEMPERATURE -20°C + 80°C
BENDING RADIUS 15 times overall diameter of cable	WORKING VOLTAGE 50 V max
TEST VOLTAGE 2000 V	FLAME RETARDANT TEST CEI 20-35/1-2, EN 60332-2-1, CEI 20-22/3-4, EN 60332-3-24, IEC 60332-3-24
NON-HALOGEN VERIFICATION 0,5 % (CEI 20-37/2-1, CEI EN 50267-2-1, IEC 60754-1) CORROSIVITY OF COMBUSTION GASES Ph: > 4,3 Conductivity: < 10 Μs/mm (CEI 20-37/2-2, CEI EN 50267-2-2, IEC 60754-2) SMOKE DENSITY Transmission of light: > 60% (CEI 20-37/3-1) TOXICITY INDEX < 2 (CEI 20-37/7)
