Description: | |
|
Materials: | |||||||
|
|||||||
Technical characteristics: | |||||||
|
|||||||
Electrical characteristics | |||||||
Frequency, MHz | Attenuation, dB/100m | PSNEXT, dB | Low value PS-ACR, dB/100 m | ||||
---|---|---|---|---|---|---|---|
0.772
|
1.8
|
64.0
|
62.2
|
||||
1.0
|
2.0
|
62.0
|
60.0
|
||||
4.0
|
4.1
|
53.0
|
48.9
|
||||
8.0
|
5.8
|
48.0
|
42.2
|
||||
10.0
|
6.5
|
47.0
|
40.5
|
||||
16.0
|
8.2
|
44.0
|
35.8
|
||||
20.0
|
9.3
|
42.0
|
32.8
|
||||
25.0
|
10.4
|
41.0
|
30.6
|
||||
31.25
|
11.7
|
39.0
|
28.3
|
||||
62.5
|
17.0
|
35.0
|
18.0
|
||||
100.0
|
22.0
|
32.0
|
10.0
|
||||
Conductor resistance at 20°C (68°F) | 9.38 Ohm/100 m (2.9 Ohm/100 ft) | ||||||
Resistance Unbalance | 3% | ||||||
Capacitive unbalance at the frequency of 1 kHz | 330 pF/100 m (101 pF/100 ft) | ||||||
Resistance at the frequency of 1-100 MHz | 100 ± 15 Ohm | ||||||
Capacity at the frequency of 1 kHz | 50 ± 4 pF/m | ||||||
Propagation velocity | 68% |
