140518. HCTAY-50-22(7/8") Common

HCTAY-50-22(7/8") Common

Detailed description

Cable Structure
Inner conductor ø mm	9.0 Smooth CU tube
Insulation ø mm	22.3
Outer conductor ø mm (Ring CU tube & slot )	24.9
Outer jacket mm	27.5
Mechanical characteristics
Maximum tension(N)	1440
Repeated bending radius(mm)	250
Storage temperature(°C)	–55 ～ +80°C
Installation temperature(°C)	–40 ～ +80°C
Electrical characteristics
Characterristic Impedance (Ohm)
100-2500 MHz	50.0
Voltage standing-wave ratio
800-1000 MHz	1.15
1700-2200 MHz	1.20
Peak power(KW)	91.0
Cut-off frequency(Ghz)	5.2
Attenuation constant(dB/100m) Typical value
900 MHz	3.85
1800 MHz	5.74
2400 MHz	6.79
