It provides 4 10/100Mbps UTP/STP RJ45 ports with auto-MDI/MDIX and 1 fiber port. It also provides powerful functions such as supporting Web management, intelligent matching among working mode, port, VLAN, prority, data rate and security of the interface.
Key Features:
Support 4 10/100M auto-detect Half/Full duples RJ45 ports and 1 fiber port.
Support potr-based VLAN and MTU VLAN function
Support Port Security, Broadcast Storm control, Bandwidth Control(the minimum Granularity is 128Kbps)
Support data packet length up to 1552 bytes
Support MAC address auto-learning.
Support transmission by single fiber and dual fibesr.
External power supply
Standard:
|
IEEE802.3,IEEE802.3u ,IEEE802.3x
|
Protocol:
|
CSMA/CD
|
Port:
|
4 MDI/MDIX RJ45 prots and 1 fiber port
|
Input Voltage:
|
AC100V-AC240V/50-60Hz
|
Operational Temperature:
|
0 ºC~ 50 ºC
|
Storage Temperature:
|
-30 ºC~ 60 ºC
|
Humidity:
|
5%~90% non-condensing
|
Dimensions
|
232mm*142mm*45mm
|
|
