130506. All In One Box Camera
All In One Box Camera
Detailed description
Features
1. Electronic shutter speed changeable
2. BLC area selectable
3. AGC changeable
4. White balance mode selectable
5. Zoom Lens
6. With mirror function
7. Motion detection on/off
| Model | DF-628CD | DF-628HD |
| Image Sensor | 1/4” Sony Super HAD CCD | 1/3” Sony Super HAD CCD |
| Pixels(H×V) | P:752(H) ×582(V) N:768(H) ×494(V) | |
| Scanning System | PAL/NTSC | |
| Horizontal Resolution | 480 TVL | 600TVL |
| Synchronization | Internal | |
| Minimum Illumination | 0.05Lux/F1.2 | |
| Backlight Compensation | Automatic | |
| Electronic Shutter | 1/50(60)~1/100,000 Sec. | |
| White Balance | Automatic | |
| Lens | F=3.9-85.8mm | |
| Optical Zoom | 22X | |
| S/N Ratio | ≥48DB | |
| Gamma Correction | 0.45 | |
| Video Output | 1.0Vp-p/75Ω | |
| Operation Temperature | -20~55℃ | |
| Power Supply | DC 12V, 1,000mA | |
| Dimensions (mm) | 107×58×71mm | |
| Weight (g) | 420g | |
